METALLKRAFT Szerszámélező köszörűgép PP50 univ(fúró, eszterga, szár-és tárcsamaró)
Megrendelésre
Egységár (darab):
Bruttó: 2.680.335 Ft
Nettó: 2.110.500 Ft
Cikkszám:
7211PP50Márka:
METALLKRAFTA termék az alábbi kategóriákban található:
KöszörűgépLeírás
PP50 universal tool grinder with CE
The Universal Tool Grinder is offered by Peiping Precision Enterprise Co., Ltd., a Taiwan based OEM_ODM manufacturer and supplier of Tool Grinder, Drill Grinder, Cutter Grinder, Carving Tool Grinder, Drill Sharpener, Universal Grinder, Grinder.
With variety of options can be provided for different purposes
Tilting wheel head. It could be tilted easily and swiveled 360° on the horizontal plane. Both of these features make it easy to set the rake and relief angles and make for a wide angle or grinding
Adopt precise roll guide on the table, it make the table is stable and operated smoothly.
PP-50
Specifications:
* Longitudinal travel of table: 230mm
* Cross travel of saddle: 180mm
* Vertical adjustment of wheel head: 120mm
* Rotary angle of wheel head: 360°
* Rotary angle of up-down spindle: 360°
* Working table area: 620 x 190mm
* Size of wheel:
o 180 x 25 x 31.75mm
o 125 x 50 x 31.75mm
* Speed of wheel: 3,600 RPM
* Motor: 3/4 HP, 110V / 220V / 380V
* N.W. / G.W.: 280kgs / 320kgs
* Size of packing (L x W x H): 1,000 x 850 x 1,540mm
Features:
With variety of options can be provided for different purposes.
Simple to set up.
Easy to operate.
Grinding fast and high accuracy.
Certificate:
CE (option)
Standard accessories:
a. Grinding Wheel 2 pcs
b. Grinding Wheel Flange2 sets
c. Wheel dresser 1 pc
d. Halogen lamp1 pc
e. Tool for general use1 set
Options with surcharge :
*50B Drills & Taps Grinding Attachment1 set (Including Standard Accessories Listed Below:)
a. Morse taper sleeve no.3,4,53 pcs
b. Cam No.4 for drill grinding 1pc
c. Cam No.6 for drill & step drill grinding 1pc
d. Cam No.8 for 4 flutes tap grinding 1pc
e. Cam No.9 for 3 flutes tap & 3 flutes counter sink grinding 1pc
f. Cam No. A2 for one flute counter sink grinding 1pc
*50E R type mills & cutters grinding attachment : 1 set (Including Standard Accessories Listed Below:)
a. Collet (6/8/10/12/16/20/25mm) 7 pcs
*50F Lathe tools grinding attachment 1 set
*50K Drills & Tap & counter sink & end mills grinding attachment 1 set
*50D End Mills grinding attachment 1 set
*50H Tools grinding attachment 1 set
*Cooling systeM 1 set
*Auto cycle motor (for 50B) 1 set
